Description
| Number of wires x Rated cross-section | Number of indiv. Wires Guided value | Diameter of indiv. Wires max. | Diameter of cond. Max. | Resistance at 20°C max. | Insulation wall thickness Rated Value | Core diameter | Sheath thickness Guide value | External diameter | Weight approx. | ||
| mm2 | mm | mm | mΩ/m | nom. Mm |
nom. Mm |
nom. Mm |
min. Mm |
max. Mm |
Kg/ 1000m | ||
| 2×0.50 | 16 | 0,21 | 1,10 | 37,1 | 0,40 | 1,7 | 0,60 | 4,9 | 5,3 | 34 | |
| 2×0.75 | 24 | 0,21 | 1,30 | 24,7 | 0,40 | 2,0 | 0,70 | 5,9 | 6,3 | 39 | |
| 2×1.00 | 32 | 0,21 | 1,50 | 18,5 | 0,50 | 2,4 | 0,80 | 6,8 | 7,2 | 47 | |
