Description
| Type designation | Number of wires x Rated cross-section |
Number of indiv. wires Guided value | Diameter of indiv. wires max. | Diameter of cond. max. | Resistance at 20°C max. | Isolation wall thicknees Rated value |
External Diameter | Weight approx. |
| mm2 | mm | mm | mü/m | mm | mm | kg/1000m | ||
| FLRY TP | 2×0.500 | 16 | 0.21 | 1.10 | 37.1 | 0.3 | 3.2 | 12 |
| FLRY TP | 2×0.75 | 24 | 0.2 ID | 1.30 | 24.7 | 0.3 | 3.8 | 18 |
| FLRY TP | 2×1.00 | 32 | 0.21 | 1.50 | 18.5 | 0.3 | 4.2 | 22 |
| FLRY TP | 2×1.50 | 30 | 0.26 | 1.70 | 12.7 | 0.3 | 4.8 | 33 |
| FLRY TP | 2×2.50 | 50 | 0.26 | 2.20 |
7.6 |
0.3 | 6.0 | 50 |
