Description
| Number of wires x Rated cross-section |
Number of indiv. Wires Guided value |
Diameter of indiv. Wires max. |
Diameter of cond. Max. |
Resistance at 20°C max. |
Insulation wall thickness Rated Value |
External measurement width |
External measurement Height |
Weight approx. |
||
| mm2 | mm | mm | mΩ/m | nom. Mm |
min. Mm |
max. Mm |
min. Mm |
max. Mm |
kg/1000m | |
| 2×0.50 | 16 | 0,21 | 1,10 | 37,1 | 0,3 | 1,4 | 1,6 | 3,0 | 3,2 | 12 |
| 2×0.75 | 24 | 0,21 | 1,30 | 24,7 | 0,3 | 1,7 | 1,9 | 3,6 | 3,8 | 18 |
| 2×1.00 | 32 | 0,21 | 1,50 | 18,5 | 0,3 | 1,9 | 2,1 | 4,0 | 4,2 | 22 |
| 2×1.50 | 30 | 0,26 | 1,70 | 12,7 | 0,3 | 2,2 | 2,4 | 4,6 | 4,8 | 33 |
| 2×2.50 | 50 | 0,26 | 2,20 | 7,6 | 0,4 | 2,7 | 3,0 | 5,8 | 6,0 | 50 |
| 2×0.75 | 24 | 0,21 | 1,20 | 26,0 | 0,5 | 5,2 | 5,4 | 2,2 | 2,4 | 23 |
